DCC Specialties 246-JACKSNAPHV Jack Wabbit Accessory/Turnout Decoder — For High-Voltage Snap Coil Turnout Motors

The Jack Wabbit is a Quad version of our popular Hare and Wabbit Intelligent
Accessory Decoders. This decoder has four fully functional intelligent decoders
on one printed circuit board. The four decoders operate independently and each
one has all of the advanced features and much more, compared to our popular Hare
and Wabbits. The Jack Wabbit is compatible with all types of turn-out motors,
including stall motors, snap coils, servos and all others!

DCCSpecialties Jack Wabbit, Snap Coil, LocoNet

Jack Wabbit Quad: 4 Outputs in one Stationary Decoder

Auto Throw

Automatically throws points when a train is approaching against the points!

Auto Throw Timer

Provides for timing the auto throw function to prevent two trains from
colliding.

Auto Return

Automatically returns the points after a preset interval for any/all operational
events.

Smart Route

Sets up to 13 routes by simple address programming in addition to the primary
address.

Dispatcher Over-Ride

Allows the Dispatcher to lock out any or all other switch commands.

Lock Block Protection

Overrides the Jack WABBITS operation if a designated block is occupied.

Locked Route Control

Provides for only one route direction response for a Throw or Clear command.

Smart Default Ops

Programmed power up response to either power off position, throw, or clear.

Operate Switch Signals or Panel LED Indicators by direct LED connections.

Manual Pushbutton or Toggle Switch

Allows button or toggle switch manual control of the points.

DCC Reset

CV 63=42, Sets Any or All Addresses and CVs to original factory default values.

Decoder Reset By Jumper

Jumper selection resets entire Jack Wabbit to factory default Address and CVs.

Direct Current Ops

The JACK WABBIT will operate on DC using the Manual Push Button Control Option.

Semaphore/Gate Ops

Uses a stall motor and Auto Throw for triggered control of a semaphore or
crossing.

Automates Reverse Loop Turnouts

Using Auto Throw feature.

Feed Back, Turnout Position Reporting to

Digitrax (LocoNet), Lenz (ExpressNet) and NCE (Cab Bus)
